Image Sensor
1/2.8" Progressive Scan CMOS
Max. Resolution
2560 × 1440
Day & Night
IR cut filter
Zoom
4x optical, 16x digital
Focal Length
2.8 to 12 mm
FOV
Horizontal FOV 96.796° to 31.68°, vertical FOV 51.16° to 17.798°, diagonal FOV 115.13° to 36.32°
Focus
Auto, semi-auto, manual
Pan Speed
Pan speed: configurable from 0.1° to 100°/s; preset speed: 100°/s
Tilt Speed
Tilt speed: configurable from 0.1° to 100°/s, preset speed 100°/s
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720); 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Audio Compression
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM/AAC
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Image Parameters Switch
Yes
Image Settings
Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch
Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)
120 dB
Ethernet Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in memory card slot, support microSD/SDHC/SDXC card, up to 256 GB
Protection
IP66 (IEC 60529-2013), IK10, TVS 4000V lightning protection, surge protection and voltage transient protection
