Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.01 Lux @ (F2.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Angle Adjustment
Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
Lens Type
Fixed focal lens, 2.8 mm, 3.6 mm and 6 mm optional
Focal Length & FOV
2.8 mm, horizontal FOV: 101°, vertical FOV: 56°, diagonal FOV: 118° 3.6 mm, horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92° 6 mm, horizontal FOV: 49.2°, vertical FOV:28.3 °, diagonal FOV: 56.1°
Image Settings
Anti-Banding, Brightness, Sharpness, Smart IR
Frame Rate
TVI: 1080P @ 30 fps, 1080P @ 25 fps AHD: 1080P @ 30 fps, 1080P @ 25 fps CVI: 1080P @ 30 fps, 1080P @ 25 fps CVBS: PAL/NTSC
Day/Night Mode
Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR)
Digital WDR
Image Enhancement
DWDR/BLC/HLC/Global
White Balance
Auto/Manual
Video Output
Switchable TVI/AHD/CVI/CVBS
Power
12 VDC ± 25%, max.9.8 W,*You are recommended to use one power adapter to supply the power for one camera.
Material
Front cover: Metal Main body: Plastic
Dimension
192.6 mm × 178.3 mm × 71 mm (7.58" × 7.02" × 2.8")
Weight
Approx. 738 g (1.63 lb.)
Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Communication
HIKVISION-C
Protection
IP67
