Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Angle Adjustment
Pan: 0° to 360°,Tilt: 0° to 90°,Rotate: 0° to 360°
Lens Type
2.8 mm and 3.6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 105°, vertical FOV: 56°, diagonal FOV: 126° 3.6 mm, horizontal FOV: 84°, vertical FOV: 46°, diagonal FOV: 98°
Supplement Light Type
IR, White Light
Smart Supplement Light
Yes
Supplement Light Range
IR: Up to 20 m,White Light: Up to 20 m
Image Parameters Switch
STD/HIGH-SAT/HIGHLIGHT
Image Settings
Brightness, Sharpness, Anti-banding, AGC
Frame Rate
TVI: 1080p @25 fps/30 fps CVI: 1080p @25 fps/30 fps AHD: 1080p @25 fps/30 fps CVBS: PAL/NTSC
Day/Night Mode
Auto/Color/BW (Black and White)
Wide Dynamic Range (WDR)
Digital WDR
Noise Reduction
3D DNR/2D DNR
White Balance
Auto, Manual
Image Enhancement
DWDR, BLC, HLC, Global
Video Output
Switchable TVI/AHD/CVI/CVBS
Power
12 VDC ± 25%, max. 2.9 W,*You are recommended to use one power adapter to supply the power for one camera.
Dimension
161.1 mm × 68.4 mm × 65.2 mm (6.34" × 2.69" × 2.57")
Weight
Approx. 235 g (0.52 lb.)
Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing)
Communication
HIKVISION-C
Protection
IP67
