Image Sensor
1/2.7" Progressive Scan CMOS
Max. Resolution
2560 × 1920
Lens Type
Fixed focal lens, 1.05 mm
Focal Length & FOV
1.05 mm, horizontal FOV: 180°, vertical FOV: 180°, diagonal FOV: 180°
Depth of Field
0.1 m to ∞
Main Stream
50 Hz: 25 fps（2560 × 1920, 2048 × 1536, 1280 × 960） 60 Hz: 30 fps（2560 × 1920, 2048 × 1536, 1280 × 960）
Sub-Stream
50 Hz: 25 fps (640 × 480) 60 Hz: 30 fps (640 × 480)
Video Compression
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG
Video Bit Rate
32 Kbps to 16 Mbps
H.264 Type
Baseline Profile,Main Profile,High Profile
Region of Interest (ROI)
1 fixed region for main stream
Audio Bit Rate
64 Kbps (G.711 ulaw/G.711 alawm/16 Kbps (G.722.1)/16 Kbps (G.726)/32~160 Kbps (MP2L2)/16~64Kbps (AAC-LC)
Audio Sampling Rate
8 kHz/16 kHz
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users 3 user levels: administrator, operator, and user
Client
iVMS-4200,Hik-Connect,Hik-Central
Security
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
Web Browser
Plug-in required live view: IE 10+, Local service: Chrome 57.0+, Firefox 52.0+
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Alarm 1 input, 1 output (max. 12 VDC, 30 A)
