Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Max. Resolution
Channel 1: 1920 × 1080; Channel 2: 1920 × 1080
Min. Illumination
Color: 0.005 Lux @ (F1.2, AGC ON)
Shutter Time
1 s to 100,000 s
Lens
Focal Length & FOV
L10 model: 3.7 mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1° L20 model: 2.8 mm, horizontal FOV 93.8°, vertical FOV 51.7°, diagonal FOV 109.3° 3.7mm, horizontal FOV 77.5°, vertical FOV 39.4°, diagonal FOV 94.1° L30 model: 2.8 mm, horizontal FOV 109.0°, vertical FOV 60.0°, diagonal FOV 128.3° 4 mm, horizontal FOV 82.8°, vertical FOV 45.1°, diagonal FOV 98°
Lens Mount
L10/L20: Mini; L30: M12
HEOP
Open Resources
Memory: 60 MB, Smart RAM: 375 MB, eMMC: 2 GB
Deep Learning Structure
Caffe,PyTorch,TensorFlow
Programming Language
C,C++
Video
Main Stream
50 Hz: 50 fps (1920 × 1080, 1280 × 960, 1280 × 720) 60 Hz: 60 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Network
Protocols
TCP/IP, SRTP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets
Simultaneous Live View
Up to 20 channels
Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Audio
1 input (line in), 1 output (line out)
Alarm
2 inputs, 1 output (max. 12 VDC, 30 mA)
RS-485
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
USB
1 micro USB 2.0 interface
General
Power
12 VDC ± 20%, 0.53 A, max. 6.4 W, PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W
Material
Main body: Aluminum Alloy+PC
Dimension
105 mm × 78 mm × 26 mm (4.13" × 3.1" × 1.02")
