DS-K4H250S(O-STD)

DS-K4H250S(O-STD)

Código de material:302900530

DS-K4H250S

Solo 25 cantida en stock
$ 276.370,00
IVA excluído
Cantidad



Políticas de Seguridad



Políticas de envio



Políticas de Devolución

General

Indicator
Red (Door is Unlocked) Green (Door is Locked)
Power supply
12 VDC/500 mA 24 VDC/250 mA
Working temperature
-10°C to +55°C (14°F to 131°F)
Working humidity
0 to 95% (Relative Humidity)
Dimensions
Lock body: 240×49×25.5mm (9.45×1.93×1.00") Armature Plate: 180×38×11mm (7.1×1.5×0.4")
Weight
2.1kg (4.63lb)
Material
Shell: hard Anodizing Electroplating Operated Lock Body: eco-friendly Zinc with Electroplating Operated Armature Plate: eco-friendly Zinc with Electroplating Operated
Thrust
Max. 272 kg (599.8 lbs) Linear Thrust
Door type
Single leaf,Double leaf, Wooden Door, Glass Door, Metal Door, Fireproof Door
Signal output
Dry Contact Signal Output, Support Maximum Power Rate of 3A, NO Output While Locking and NC Output While Unlocking
